Product specifications:
Compatible models: UFO P70, U80 Max, R20 Max, R90 Max
Contrast: 1000:1±200
Synchronous frequency: 96/100/120/144Hz
Synchronization method: DLP-Link
Transmittance: 38%±2%
Rated working current: <1.2mA
Viewing angle: 30° (L/R15°)
Response time: 2ms±0.5ms
Operating time: (fully charged) 40hr±5hr
Operating temperature: 0℃~45℃
Storage temperature: -10℃~60℃
Operating humidity: 20%~80%RH
Glasses power supply: Rechargeable lithium battery 3.7V45mAh
Atmospheric pressure: 86kPa~106kPa
Weight: 34.5g
Instructions for use:
1, Charge the 3D glasses.
2, use the projector to play 3D film sources, common 3D film source formats (left-right format, top-bottom format, Blu-ray 3D);
3, Press the “button” on the 3D glasses once to turn on the 3D glasses.
4, Depending on the angle of view of the movie, each time you press the “button” on the 3D glasses, the left and right angle of view will switch.
Charging instructions:
1, Use the USB cable from the micro USB port of the 3D glasses to connect to a computer or USB charging case for charging only.
2, The indicator light will be red when charging, and the red light will be off when fully charged.
3, Charging time: 2-3 hours. Continuous use: 50 hours once.
4, If you do not use it for a long time, please charge the battery at least once every 6 months.
Package contents:
3D glasses x 1
USB cable x 1
Cleaning cloth x 1
Manual x 1
Attention:
●Shutter 3D glasses are only compatible with DLP-Link3D projectors or DLP-Link3D TVs. Polarized 3D, cinemas, regular TVs, PC monitors and laptops are not supported.
●There is a protective film on both sides of the lens, so it is necessary to remove the protective film before use.
