About X15

About X15 Smart Version android OS firmware upgrade

X20 android projector support OTA online update Android firmware. Every time we update the firmware, after uploading to the cloud server, K45 Smart Version will prompt to update, Operation video guide: https://youtu.be/zC4GxpWZMeQ

It can also be upgraded via U disk

Operation method 1：

1. You can click the icon below to download the firmwareof X20 Android. Unzip files, Do not change the name of the file, otherwise the projector will not recognize it.
2. Copy the firmware to the root directory of the U disk. Note: Do not put it in other folders.
3. Turn on the projector and let the projector work normally.
4. Insert the U disk into the USB 1 port of the projector
5. Enter the file management, find the files in the U disk, and check whether the firmware has been copied to the U disk.
6. Operating the projector, enter “Settings” – “System Upgrade” – “Local Upgrade” in turn, Follow the prompts to upgrade
7. Wait for the projector to upgrade, do not power off or terminate the projector upgrade in the middle, otherwise the projector will not work.

Note: the upgrade process must not be interrupted.

Operation method 2：（For users who cannot upgrade with the first method.）

1. You can click the icon below to download the firmwareof X20 Android. Unzip files, the name of the firmware is “YG_6M021.bin”. Do not change the name of the file, otherwise the projector will not recognize it.
2. Copy the firmware to the root directory of the U disk. Note: Do not put it in other folders.
3. Insert the U disk into the second USB port of the projector
4. Connect the projector to the power supply, turn on the power switch, and wait for a few seconds
5. Then long press the power button until the upgrade progress bar appears on the screen, and release the button.
6. Wait for the projector to upgrade, do not power off or terminate the projector upgrade in the middle, otherwise the projector will not work.

Note: the upgrade process must not be interrupted.

Firmware upgrade operation guide video: https://youtu.be/q3iE25mslrY

Firmware version: 2023_1216

About X15 Smart Version Wifi-display Function

With the development of science and technology, in the current Bluetooth function, it is no longer used for Bluetooth to transfer files. The role of Bluetooth is only to transmit sound. The Bluetooth file transfer function has been replaced by APP.

Wifi, Bluetooth, wifi-display (airplay, Miracast, DLNA) are all different functions. The effects are different.

  wifi-display function, the projector displays the image and sound of the mobile phone screen through the mirroring function of the smartphone. This is not achieved using the Bluetooth function. It is achieved through the screen mirroring function that comes with the phone.

1. ios smartphonerealizes screen mirroring via projector’s “iMirror”app

Operation instruction video connection: https://youtu.be/XyWQC5pPFOM

2. Android smartphonesrealize screen mirroring via projector’s “eshare”app

Operation instruction video connection: https://youtu.be/ASYcV__UrvA

Note: Not all Android smartphones support the screen mirroring function. For smartphones that support screen mirroring, there are options similar to this in the “Settings” or “More Functions” options of the smartphone, for example: “Screen mirroing”, “Wifi-display”, “multi-screen”, “screen projection”, “play to”, “media output”, etc.

If the projector’s pre-installed screen mirroring app is not compatible with your Android smartphone, you can also download and install Airscreen, happycast and other apps that support wifi-display on the projector.

Tips：

Some video apps with copyright protection cannot support wireless projection from other devices to the projector. For example, Netflix, iTunes Movie, Google Movie, Amazon Prime do not support this function on some smartphone and computers. All Android system projectors on the market are the same.

X15 Projector Operation Guidance Video

1. How to adjust BYINTEK X15basic electronic digital zoom?

Operation instruction video connection: https://youtu.be/ALF2CVYHOJ8

X15 Smart Version Projector Operation Guidance Video

1. How to connect laptop Computer to BYINTEK X15 Smart projector?

Operation instruction video connection: https://

On the computer desktop, you can set 3 display modes

1. Duplicate mode: computer and projector display the same screen
2. Extended mode: The projector displays the extended screen of the computer
3. Display only monitor 1: Only display the laptop screen
4. Display only monitor 2: Only display the projector screen

2. How to use the BYITNEK X15Smart Version projector (how to turn it on)?

Operation instruction video connection: https://youtu.be/YCXMakiDq10

3. How to check the system version information of BYINTEK X15Android projector?

Operation instruction video connection: https://youtu.be/oEA-2HAtVMQ

4. How to change the system language of BYINTEK X15Android?

Operation instruction video connection: https://youtu.be/0eJP_IWE_rk

5. How to set the default signal source of BYINTEK X15Android after booting, for example to HDMI by default?

Operation instruction video connection: https://youtu.be/qWhRzVmYxP8

6. How to operate BYINTEK X15Smart Version to restore factory settings?

Operation instruction video connection: https://youtu.be/LzGaxHaAKLY

7. How to set BYITNEK X15Smart Version to flip the screen image during ceiling mount or rear projection?

Operation instruction video connection: https://youtu.be/xjNnnIlCqYk

8. How to adjust the keystone correction of BYITNEK X15Smart Version（Includes corner keystone）?

Operation instruction video connection:

enable automatic keystone correction: https://youtu.be/u809iqlJymU

manual corner keystone correction: https://youtu.be/6Ivvesz9aAo

manual vertical and horizontal keystone correction: https://youtu.be/GJVb9p9tpJQ

9. How to adjust the electronic zoom (screen image zoom) function of BYINTEK X15Smart Version?

Operation instruction video connection: https://youtu.be/RQ49KyTW65o

10. How to operate X15Android to upgrade via network OTA?

Operation instruction video connection: https://youtu.be/2wESdGOH0HE

11. How to operate X15Android to update firmware via U disk?

Operation instruction video connection: https://

12. IPhone wireless display to BYINTEK X15 Smart Version projector operation guide

Operation instruction video connection: https://youtu.be/XyWQC5pPFOM

13. Android smartphone wireless display to BYINTEK X15Smart Version projector operation guide

Operation instruction video connection: https://youtu.be/ASYcV__UrvA

14. How to control the projector to automatically play videos, pictures, advertisements
15. APK download link:https://we.tl/t-pMsCgqdnze
16. Download and install on the projector, APK name:look digital signage
17. Then link the projector and computer in the same network
18. After the projector installs this APK, open the APP device will prompt a code: similar to 875587
19. Log in to this website “https://app.lookit.hk/signin” on the computer, register the account to activate, enter the control page, enter the device code of the projector, and add the projector device
20. You can set the content you want to play through the computer in the background of this website.
21. Every time you start the projector, the projector will automatically play the set advertisement video or picture.
22. The K25 Smart Version projector can be set to start automatically when it is powered on. Operation steps: https://

15. How to solve Fire TV stick 4K connected to the projector to play movies no sound？

Turn off Dolby in the setting sound of Fire TV stick 4K.

         Step：”setting”—-“display&Sound”—“Audio”—“Dolby digital output”—“Dolby digital plus OFF”, Turn off Dolby，Do it a few times，Confirm whether Dolby is successfully turned off.

         Tips: Some sources can work normally without turning off Dolby and setting them to automatic mode. If there is still no sound in automatic mode, you must turn off Dolby.

         Operation video guide：https://youtu.be/2S77xzLHC84

X15 Series Projector Maintenance Guide

1. How to solve the problem of remote control not working?

1.1 The projector comes standard with a 2.4G wireless remote control. If the remote control does not work, you need to re-operate the remote control to pair with the projector.

The operation method is to take out the battery of the remote control, start the projector, wait for the projector to turn on, then move the remote control close to the projector, and then install the battery of the remote control, and the remote control will re-pair with the projector.

1.2 One remote control can only correspond to one projector, and cannot be used for two K45s at the same time.

1.3 If the pairing is unsuccessful, replace a remote control and try again.

1.4 If the replacement of the remote control still fails, it may be that the cable between the remote control receiver and the motherboard is loose. Reconnect the cable between the receiver and the motherboard.

1.5 If there is still a problem, there may be a problem with the remote control receiving circuit board or the main board. Just replace the corresponding parts. There is a disassembly video guide below.

2. How to replace the dust filter of BYINTEK X15series projector?

Fault phenomenon: If the projector has been used for a long time, the projector often shuts down automatically, or the projector screen slowly turns yellow, there may be too much dust on the filter screen. Remember to clean the dust on the filter screen regularly to ensure the normal heat dissipation of the projector.

Operation guide video URL: https://

3. Disassemble the projector to clean up the dust on the LCD of BYINTEK X15series projector

Fault phenomenon: If you find black dust-like dots on the projection screen, it means that there is dust or foreign matter on the LCD surface inside the projector, which needs to be disassembled and cleaned up.

Operation guide video URL: https://youtu.be/_Zrwkbam7T8

4. The lens of the BYINTEK X15projector has no light coming out, and the LED does not work, how can I solve it?

Fault phenomenon: After the projector presses the power button, you can hear that the fan inside the projector is working normally, but there is no light coming out of the lens at all, maybe the LED is not working.

First, disassemble the projector to check whether the cables on the power board are connected properly. If the cables on the power board are connected normally and there is no looseness, the projector still does not work, and a new power board needs to be replaced. If it is still not normal, you need to replace the LED. If the lens still has no light after replacing the LED, you need to replace the motherboard.

Usually replace the power board projector is normal. LED damage is generally caused by high voltage breakdown of the projector’s LED due to lightning strikes or unstable household power grids.

Operation guide video URL: https://youtu.be/-HN80NSPqBU

5. Replace the power board of BYINTEK X15series projector

Fault phenomenon: The power indicator on the top cover of the projector is not on, or there is no light coming out from the inside of the projector lens (that is, the LED does not work), it may be a problem with the power board, and the power board needs to be replaced

Operation guide video URL: https://youtu.be/44w0QuoQKE4

6. Replace the focus motor of BYINTEK X15series projector

Fault phenomenon: If you press and hold the “F+” and “F-” buttons of the remote control, the projector lens cannot move back and forth, that is, it cannot be focused. It may be that the focusing motor is not working, or the circuit board connected to the focusing motor is not working. Replace both parts.

Operation guide video URL: https://youtu.be/UnN0HkUl7FA

7. Replace the cooling fan of BYINTEK X15series projector

Operation guide video URL: https://youtu.be/iWMLFPM-xew

8. Replace the motherboard of BYINTEK X15series projector

Operation guide video URL: https://youtu.be/xYP4Unm0LnE

9. How to replace the LCD of the BYINTEK X15projector?

Fault phenomenon: If the picture image is abnormal, there are colored streaks, or there are cracks, black blocks that will not recover after the projector cools down, etc., the LCD may be damaged and the LCD needs to be replaced.

Disassemble the projector, use the mobile phone to shoot the text on the LCD cable for your after-sales customer service, the customer service will send it to you according to the corresponding LCD arrangement, and the projector system firmware used for different LCDs is different. If a different LCD is replaced, it will cause the projected image to display abnormally. At this time, the customer service needs to send you the system firmware corresponding to the LCD you received, copy the program to the U disk and directory, and insert it into the USB of the projector. Then connect the projector to the power supply, wait for a few seconds, then press and hold the power button for 10 seconds, then release the button, let the projector update the program automatically, wait for 10 minutes, if the projector has an image, it means it is normal.

Operation guide video URL: https://youtu.be/JLCpWNa_kkQ

10. What should I do if the remote control does not respond? How to replace the 2.4G remote control receiver inside the BYITNEK X15 series projector?

Solution:

1. Turn on the projector first, then remove and re-install the batteries of the remote control.
2. If it still doesn’t work, please replace the remote
3. If replacing the remote control does not work, please replace the remote control receiver inside the projector

Replacing the remote control receiver inside the projector, operation guide video URL:  https://youtu.be/6U5sPlodux4
